V-LOCK

ES8000 V-Lock
-Holding Force : Maximum 1000kg
-Bolt Dimensions : 11mm Diameter, 20.5mm Projection
-Duty Cycle : > 300,000 operations
-Warranty : 5 years warranty
-The ES8000 is a micro-processor controlled motorized lock with built-in over current sensing and automatic re-locking ability.The lock is designed to be controlled with battery backed 12-24 V dc power supply and connected with a minimum of 3 wires, plus 2 additional wires for bolt monitoring.(refer to the wiring details below)

ES8000 V-Lock
Trimac Technology's new V-Lock introduces patented features that overcome the problems of door misalignment in 180 degre swinging doors and the problems of side load.
This new high-torque motorized lock can be concealed from view or surfacce mounted, and has the worlds' first fail-open motor locking mechanism which eliminated the need and cost of an additional key override.

price 28,000 ฿+VAT+Power supply+Installation Please,contact: K.Cherry 02-889-1657,081-814-4255
