Flow Meter ,Tokiko,Actaris,Elster,Ampty Email

AICHI-TURBINE GAS METER
MODEL : Turbine Meter TBX100L
MODEL : Turbine Meter TBX100F
MODEL : Turbine Meter TBX150F
MODEL : Turbine Meter TBX30L
MODEL : Turbine Meter TBX30R
MODEL : Turbine Meter TBZ60-0
MODEL : Turbine Meter TBZ60-3.5
MODEL : Turbine Meter TBZ60-9.9
MODEL : Turbine Meter TBZ150-0
MODEL : Turbine Meter TBZ150-3.5
MODEL : Turbine Meter TBZ150-9.9
MODEL : Turbine Meter TBZ300-0
MODEL : Turbine Meter TBZ300-3.5
MODEL : Turbine Meter TBZ300-9.9

EMAIL : DIAPHRAGM GAS METER
Maximum Capacity : 7.5m/hr for NG, 10m3/hr for LPG
Cyclic Volume : 2liter (0.002 m3)
Maximum Working Pressure : 150 kpa(21.75psig)
Accuracy : better than+/-1%
operating Temperature Range : -10 to + 65C.

ELSTER - TURBINE GAS METER
Max.pressure : 16 bar(4bar for Combustible gases)
measuring Range : QA-10:1.6-16m3/hr
: QA-16:2-25m3/hr
: QA-25:2.5-40m3/hr
: QA-40:3.3-65m3/hr
: QA-65:6-100m3/hr
: QA-100:10-160m3/hr
: QA-160:13-250m3/hr
: QA-250:32-650m3/hr
Accuracy of Qmin-0.2Qmax <1%(3%ofMW)
Hosing Material : Aluminum
Out put : Low Frequency,Medium - Frequency
