COAXIAL CABLE
BRAND ORDER NO. DESCRIPTION SHIELD PACKING PRICE / M.
INTERLINK (MIL Grade) CB-0102 RG-58 C/U CABLE 50 OHMS 95เปอร์เซ็น 500 M. / RL ฿11.00
INTERLINK (MIL Grade) CB-0104 RG-59 B/U CABLE 75 OHMS 95เปอร์เซ็น 500 M. / RL ฿12.00
INTERLINK (MIL Grade) CB-0106 RG-62 A/U CABLE 93 OHMS 95เปอร์เซ็น 500 M. / RL ฿12.00
INTERLINK (MIL Grade) CB-0108 RG-6 / U CABLE 75 OHMS 95เปอร์เซ็น 500 M. / RL ฿16.00
INTERLINK (MIL Grade) CB-0110 RG-11 / U CABLE 75 OHMS 95เปอร์เซ็น 500 M. / RL ฿36.00

TWIN-AXIAL CABLE
BRAND ORDER NO. DESCRIPTION PACKING PRICE / M.
INTERLINK (USA) CB-0150 TWIN-AX CABLE 500 M. / RL ฿35.00

CABLE TV , CCTV , MATV , SATELLITE TV
BRAND ORDER NO. DESCRIPTION SHIELD PACKING PRICE / M.
INTERLINK (JIS STD) CB-0182 2.5C - 2V CABLE 75 OHMS. 95เปอร์เซ็น 100/500 M./RL ฿9.00
INTERLINK (JIS STD) CB-0184 3C - 2V CABLE 75 OHMS. 95เปอร์เซ็น 100/500 M./RL ฿11.00
INTERLINK (JIS STD) CB-0186 5C - 2V CABLE 75 OHMS. 95เปอร์เซ็น 100/500 M./RL ฿19.00
MULTI - CORE DATA CABLE
BRAND ORDER NO. DESCRIPTION PACKING PRICE / M.
INTERLINK CB-0244 MULTI-CORE 4 CORE (DOUBLE SHIELD) 500 M. / RL ฿18.00
INTERLINK CB-0248 MULTI-CORE 8 CORE (DOUBLE SHIELD) 500 M. / RL ฿28.00
INTERLINK CB-0250 MULTI-CORE 12 CORE (DOUBLE SHIELD) 500 M. / RL ฿42.00
INTERLINK CB-0225 MULTI-CORE 25 CORE (SINGLE SHIELD) 500 M. / RL ฿55.00
CATV / MATV / VIDEO / COAXIAL CABLE

Picture Part No. Description Unit Price
RG COAXIAL CABLE 75 OHM "HOSIWELL"
สำหรับระบบทีวี, ดาวเทียม, CATV, MATV, Broadcast, Video
RG6/U PE Coaxial 18 AWG Solid 75 Ohms 93เปอร์เซ็น Shield PE Insulation "HW" ฿13.00
RG11/U PE Coaxial 14 AWG Solid 75 Ohms 93เปอร์เซ็น Shield PE Insulation "HW" ฿27.00
RG59/U PE Coaxial 20 AWG Solid 75 Ohms 93เปอร์เซ็น Shield PE Insulation "HW" ฿11.00
RG6 Foam Coaxial 18 AWG Solid 75 Ohms 93เปอร์เซ็น Shield Foam Insulation "HW" ฿14.00
RG11 Foam Coaxial 14 AWG Solid 75 Ohms 93เปอร์เซ็น Shield Foam Insulation "HW" ฿33.00
RG59 Foam Coaxial 20 AWG Solid 75 Ohms 93เปอร์เซ็น Shield Foam Insulation "HW" ฿12.50
F660BV RG6 "COMMSCOPE" 60เปอร์เซ็น Shield (305 M. / Box) ฿16.00
F1160BV RG11 "COMMSCOPE" 60เปอร์เซ็น Shield (305 M. / Box) ฿35.00
F1160BV-MS RG11 W/SLING "COMMSCOPE" 60เปอร์เซ็น Shield (305 M. / Box) ฿40.00
B9116 RG6 "BELDEN" 60เปอร์เซ็น Shield (305 M. / Box) ฿16.00
B1523A RG11 "BELDEN" 60เปอร์เซ็น Shield (305 M. / Box) ฿35.00
JIS C3501 COAXIAL CABLE 75 OHMS "HOSIWELL"
สำหรับระบบกล้องวงจรปิด (CCTV)
2.5C-2V ฿8.00
3C-2V ฿10.00
3C-2V-F Flexible ฿14.00
5C-2V ฿13.00
5C-2V-F Flexible ฿17.00
5C-2V-FS Flexible W / Sling Outdoor (Hanging , แขวนกับเสาไฟ) ฿25.00
5C-2VD Double Jacket for Outdoor ฿17.00
7C-2V ฿23.00
7C-2VD Double Jacket for Outdoor ฿30.00
7C-FB ฿65.00
10C-2V ฿48.00
COAXIAL CABLE 50 OHMS "HOSIWELL"
RG8A/U Coaxial 7/0.724 mm. Strand 50 Ohms 93เปอร์เซ็น Shield PE Insulation "HW" ฿30.00
RG58C/U Coaxial 19/0.18 mm. Strand 50 Ohms 93เปอร์เซ็น Shield PE Insulation "HW" ฿12.00
COAXIAL CABLE 50 OHMS "HOSIWELL"
RGB3+4 RGB 3 Coax. 28AWG + 4 Control 24 AWG ฿55.00
RGB3+8 RGB 3 Coax. 26AWG + 8 Control 26 AWG ฿90.00

COMPUTER CABLE

Picture Part No. Description Unit Price
IBM Type 1 DATA CABLE 2 Pairs 22AWG Solid Conductor "HW" "PLUS LANs" ฿35.00

IBM Type 6 DATA CABLE 2 Pairs 22AWG Solid Conductor "HW" "PLUS LANs" ฿40.00

P/N5220 TWINAXIAL CABLE FOR P/N7362211 "HW" "PLUS LANs" ฿29.00

RG62A/U ARCNET CABLE "HW" "PLUS LANs" ฿16.00

P/N5820 THIN ETHERNET CABLE (IVORY) 305 M/BOX "HW" "PLUS LANs" ฿12.00

P/N1112A THICK ETHERNET CABLE INDOOR (YELLOW) "HW" "PLUS LANs" ฿70.00

P/N1113A THICK ETHERNET CABLE OUTDOOR "HW" "PLUS LANs" ฿160.00
P/N1922 AUI/TRANSCEIVER CABLE "HW" "PLUS LANs" ฿72.00

47

MULTICORE OVERALL SCREENED CABLE UL2464

Picture Part No. Description Unit Price
DOUBLE SHIELD / CB SERIES
APPLICATION FOR DATA CABLE , HEAVY DUTY
CB 642403 3C 24AWG ฿14.80
CB 642404 4C 24AWG ฿17.00
CB 642406 6C 24AWG ฿19.50
CB 642408 8C 24AWG ฿25.75
CB 642409 9C 24AWG ฿27.72
CB 642410 10C 24AWG ฿30.00
CB 642412 12C 24AWG ฿34.00
CB 642416 16C 24AWG ฿41.00
CB 642418 18C 24AWG ฿46.10
CB 642420 20C 24AWG ฿52.50
CB 642425 25C 24AWG ฿61.75
CB 642437 37C 24AWG ฿80.50
CB 642450 50C 24AWG ฿97.50
SINGLE FOIL SHIELD '
GQID
'MemberID
'GroupID
'RoomID
'QTopic''
QName'2
QDate]
QNote'''
NInterest
'filename'2
IP'P
Qmail'2
Band'2
Class'2
Cost'2
Percent'2
AnnounceType '2
Condition '2
Receive'2
ExpireDate
'Phone'2
Mobile'2
Address''
Province'2
Email'2
PayYear'2
delpassword '2
Promotion '
NoShow'
NoPromote '
specialcost '2
GoodOrder
'GoodCode'2
GoodBand'2
GoodStatus '2
ShopRoomID/ CF SERIES
APPLICATION FOR DATA CABLE , LIGHT DUTY
CB 642604 4C 26AWG ฿13.70
CB 642606 6C 26AWG ฿15.60
CB 642609 9C 26AWG ฿22.18
CB 642612 12C 26AWG ฿27.20
CB 642625 25C 26AWG ฿49.40
CB 642637 37C 26AWG ฿64.40

MULTIPAIRS LOW CAPACITANCE CABLE UL2919

Picture Part No. Description Unit Price
DOUBLE SHIELD / IEDC SERIES
APPLICATION FOR RS232C , RS422 , RS485 Etc.
24 AWG (0.20 SQ.MM.)
IEDC2401P 1 PAIR 24AWG ฿14.00
IEDC2402P 2 PAIRS 24AWG ฿19.29
IEDC2403P 3 PAIRS 24AWG ฿24.86
IEDC2404P 4 PAIRS 24AWG ฿30.29
IEDC2406P 6 PAIRS 24AWG ฿49.05
IEDC2408P 8 PAIRS 24AWG ฿57.10
IEDC2412.5P 12.5 PAIRS 24AWG ฿79.00
IEDC2413P 13 PAIRS 24AWG ฿82.50
IEDC2417P 17 PAIRS 24AWG ฿112.79
22 AWG (0.35 SQ.MM.)
IEDC2201P 1 PAIR 22AWG ฿17.00
IEDC2202P 2 PAIRS 22AWG ฿25.00
IEDC2203P 3 PAIRS 22AWG ฿32.10
IEDC2204P 4 PAIRS 22AWG ฿37.50
IEDC2219P 19 PAIRS 22AWG ฿159.00
48

MULTIPAIRS LOW CAPACITANCE , HIGH SPEED DATA CABLE

Picture Part No. Description Unit Price
OVERALL FOIL SHIELD / CM SERIES
APPLICATION FOR RS232C , RS422 , RS485 Etc.
24 AWG (0.20 SQ.MM.)
CM2401P 1 Pair 24AWG ฿10.98
CM2402P 2 Pair 24AWG ฿15.50
CM2403P 3 Pair 24AWG ฿18.30
CM2404P 4 Pair 24AWG ฿21.65
CM2406P 6 Pair 24AWG ฿29.90
CM2408P 8 Pair 24AWG ฿36.60
CM2412P 12 Pair 24AWG ฿51.50
CM2419P 19 Pair 24AWG ฿86.50
22 AWG (0.35 SQ.MM.)
CM2201P 1 Pair 22AWG ฿14.50
CM2202P 2 Pair 22AWG ฿21.50
CM2203P 3 Pair 22AWG ฿25.00
CM2204P 4 Pair 22AWG ฿30.50
CM2206P 6 Pair 22AWG ฿39.50
CM2208P 8 Pair 22AWG ฿45.75
CM2212P 12 Pair 22AWG ฿64.37
OVERALL FOIL SHIELD AND INDIVIDUAL FOIL FOR EACH PAIR / CMI SERIES
APPLICATION FOR RS232C , RS422 , RS485 Etc.
24 AWG (0.20 SQ.MM.)
CMI2402P 2 Pair 24AWG ฿18.25
CMI2403P 3 Pair 24AWG ฿23.00
CMI2404P 4 Pair 24AWG ฿28.25
CMI2406P 6 Pair 24AWG ฿39.00
CMI2409P 9 Pair 24AWG ฿58.00
22 AWG (0.35 SQ.MM.)
CMI2202P 2 Pair 22AWG ฿24.00
CMI2203P 3 Pair 22AWG ฿32.50
CMI2204P 4 Pair 22AWG ฿40.00
CMI2208P 28 Pair 22AWG ฿270.00

TINNED COPPER FLAT BRAID


Flat Width Nom. Thick Braid Construction Approx Equiv. Nominal Area Current Ref. Part Price/Meter
(mm.) (mm.) mm of Ind End Carrier No of Strd/Car (AWG) (mm2) (Amps) Number
0.79 0.5 0.12 16 1 24 0.2 6 HE9001 ฿2.20
1.19 0.5 0.12 24 1 22 0.31 7 HE9002 ฿3.28
2.38 0.5 0.12 16 3 19 0.61 11 HE9003 ฿6.48
3.18 0.5 0.12 24 3 18 0.91 16 HE9004 ฿9.76
4.18 0.5 0.12 24 5 15 1.52 25 HE9005 ฿16.28
6.18 0.76 0.12 24 7 14 2.13 32 HE9006 ฿22.80
9.18 0.76 0.12 48 6 12 3.65 46 HE9007 ฿39.12
12.7 0.76 0.12 48 8 10 4.87 53 HE9008 ฿52.00
15.9 0.76 0.12 48 8 10 4.87 53 HE9009 ฿52.00
49

MICROPHONE CABLE

Picture Part No. Description Unit Price
Flexible Cable
MIC 02004 1 Quad (4 Cores) 24 AWG (0.20 sq.mm.) ฿23.00
MIC 03502 1 Pair (2 Cores) 22 AWG (0.35 sq.mm.) ฿16.00

For Fixed Installation
SMC 2/20 1 Pair (2 Cores) 20 AWG (0.50 sq.mm.) ฿16.00

SMC 2/18 1 Pair (2 Cores) 18 AWG (0.75 sq.mm.) ฿26.50

Multi-Channel Microphone
MIC 4 CH 4 Channels Microphone ฿56.00
MIC 8 CH 8 Channels Microphone ฿97.00
MIC 12 CH 12 Channels Microphone ฿132.00

SPEAKER & SIGNAL CABLE

Picture Part No. Description Unit Price
Without Shield (ไม่มี Shield)
P/N 9120 1 Pairs (2 Cores) 20 AWG (0.50 sq.mm.) ฿11.50
P/N 9118 1 Pairs (2 Cores) 18 AWG (0.75 sq.mm.) ฿14.00
P/N 9116 1 Pairs (2 Cores) 16 AWG (1.31 sq.mm.) ฿26.00
P/N 9114 1 Pairs (2 Cores) 14 AWG (2.00 sq.mm.) ฿41.00
P/N 9112 1 Pairs (2 Cores) 12 AWG (3.24 sq.mm.) ฿69.50
With Foil Shield (มีอลูมิเนียมฟอยย์ชีลล์)
P/N 8218 2 Pairs (4 Cores) 18 AWG (0.75 sq.mm.) ฿33.00
P/N 8216 2 Pairs (4 Cores) 16 AWG (1.31 sq.mm.) ฿59.50
P/N 8214 2 Pairs (4 Cores) 14 AWG (2.00 sq.mm.) ฿93.
